For over 30 years, the air compressor specialists at Industrial Air Power have been supplying parts, accessories and lubricants for all brands of air compressors. Well, Cutting edge, the good news is I do have the 90. fitting with the glass check ball. My dad says he used to run these engines in the oil field rental business and every now and then a compressor would quit with these symptoms and he would crack that return fitting loose and let it leak until they finished the job, and when it came back to the shop they would take the IP to a rebuilder. Sullivan-Palatek Rotary Screw Air Compressor Sullivan-Palatek manufactures one of the most reliable, high performance, low maintenance air. 15D 20D 25D 25D4 30D7 40D 125 psi 55 80 110 95 115 166 150 psi 54 78 95 95 110 115 175 psi. Palatek 15d Manual 43-REMOVE & INSTALL NEW STATION SERVICE AIR COMPRESSORS FOR A copy of the above manual is available at the Gavins Point Project Office, Air Compressor Email: email protected COMPRESSOR TECHNICAL DATA Distributed By: MODEL 60Hz 15D 20D 25D4 25D 30D7 30DG COMPRESSOR DATA Capacity, ACFM 55 80 95 110 115 125.

Sullivan-Palatek
The Ultimate Performance Rotary Screw Air Compressor

Sullivan-Palatek industrial air compressors are available in over 65 configurations from 5hp to 400hp. Advanced rotor profile geometry and oversized radial thrust bearings are key design features that result in less wear, less heat, and longer life. Sullivan-Palatek high efficiency electric driven rotary screw air compressors provide more air at higher pressures than competitive machines.

High Efficiency
Long Life
Continuous Duty
Pressures up to 175 PSI
Capacities up to 1500 ACFMM
C-Face Flange Mount Direct Drive
Optional Acoustical Enclosures
Up to 5 Year Warranty - Conditions Apply

Reciprocating compressors and a series of specialty line shaft rotary screw compressors designed for the mining industry are also available.

Contact Applied Air Systems, Inc. to determine which Sullivan-Palatek industrial air compressor model and options package is best suited to your requirements.

FEATURES & OPTIONS:
COMPRESSOR:	Oil flooded rotary screw, continuous duty, industrial air compressor.
ELECTRIC MOTOR:	200/208/230/460/575 Volt, 3-phase, up to 400HP. 230 Volt Single Phase up to 10 HP
MOTOR STARTER:	Full voltage magnetic starter with 110 volt control. Soft start, solid state, and Wye Delta starters also available.
CONTROLS:	Full modulation, auto dual control, timed stop or constant run, optional microprocessor
INSTRUMENTATION:	Line pressure, discharge pressure, operating temperature gauge, hour meter, oil filter & separator element differential gauges.
COOLING SYSTEM:	Air cooled oil cooler/aftercooler. Updraft models include a single fan cooling motor with a large side by side after cooler - oil cooler package for easy cleaning.
LUBRICATION SYSTEM:	Palasyn 45 (4000 hour) synthetic lubricoolant. Spin on microfiber oil filters for ease of maintenance.
AIR FILTER:	Replaceable dry type.
AIR/OIL SEPARATOR:	ASME code 200 PSIG tank, high efficiency replaceable separator element
Features & available options vary between models
